February 25, 2014

This evening I painted reflections. I’m really learning a lot about making smooth gradients. It is really important to mix a lot of steps. If you don’t start with closely spaced steps, you can blend until the cows come home and you either won’t have a gradient because everything mixed together, or it won’t be smooth. Use more steps and everything just works.

Stretched Canvas Holders

My magnetic canvas holders have been working really well and I’ve been so inspired by my small pear studies that I want to do a larger piece on a 12″ x 36″ stretched canvas. The only problem is my original magnetic holders were designed for 1/8″ panels. Over the weekend I made a pair of magnetic holders for stretched canvases that are 7/8″ deep.

My original panel holders used a narrow slot to hold the 1/8″ thick panels in place. My stretched canvases are 7/8″ deep so I used a different design with a thin lip of lath to hold the canvas in place. In this photo, I’ve just glued and clamped a piece of 1  1/8″ lath to a piece of 1″ x 1″ stock. Once the glue dries, I will drill holes on the right side for the magnets.

Drilling the holes for the magnets.

The new holders supporting a 12″ x 36″ canvas.

New Light Bulb

Up here in the Pacific Northwest we don’t get a lot of sunlight, so we have to supplement with artificial light. For the past few years I have been working with 5000k full-spectrum fluorescent bulbs. These bulbs give off a natural looking, neutral white light and are available in a variety of styles from the traditional four-foot tubes to the coiled compact fluorescent bulbs that screw into standard light sockets. These bulbs are great because they don’t put out a lot of heat.

In the atelier I’ve been using a 27W CFL bulb to light my still-life tableaus. This bulb is not very bright so I have to position it close to my props and this leads to very soft shadows that are hard to discern, even when the props are in a shadow box.

Last week as I was walking the aisles of the hardware store, looking for magnets for my canvas holders, I happened to go down the electrical aisle and saw a new 19.5W LED flood light bulb that puts out 1300 lumens at 5000k.

The LED bulb was about $40 and it has been a huge improvement over the CFL bulb. It is extremely bright and the light falls in a fairly tight, 30 degree cone. This allows me to position the bulb about 6 feet back from the set, which makes it more like a point source.

With this bulb, the form shadows and cast shadows are visible, even when all of the room lights are on. The only problem with the bulb is that it weighs about a pound and this makes it hard to position in clamp-on holder. I find that if I don’t take precautions, the lamp will tend to shift over time until it is pointing at the floor.

Philips 120W Equivalent Daylight 5000K PAR38 Dimmable LED Flood Light Bulb.

Here’s an example of the light output in a darkened room. Note that the bulb is bright enough that I can position it to act more as a point-source. The chair is well lit and I still get jet-black shadows.

February 18, 2014

The string for the pears is made up of Cadmium Yellow Light, desaturated and darkened with Burnt Sienna and French Ultramarine. The lightest two steps also use Titanium White and Cadmium Red.

Here I’m working from the darkest step into the light. Since the pear it lit from the front, the darkest darks are around the perimeter.

At this point the values can be deceiving with the darks appearing much darker than they should be. It is important to stick with the plan until all of the steps can be seen in context.

I keep moving up the value scale, step by step, sculpting the three dimensional form as I go.

Four steps painted, two to go.

The pear after smoothing. My technique was to first smooth the gradient, using a bristle brush that was wiped clean every few strokes. Then I adjusted the form by alternately dabbing on bits of paint from two bristle brushes, one for darks and one for lights. I would tend to hold the brush perpendicular to the canvas and let the bristles splay a bit in order to get a nice texture. I found it was helpful to alternate between light and dark, working over the entire surface of the pear, instead of focusing on any single area.

Smoothing the second painting. You can see here that the paint has been applied fairly thickly and without a lot of fuss.

The second painting at the end of the evening.

February 17, 2014

I stayed up late to paint in the backgrounds of my pear and shadow pictures. I’m finding that it is easier to start with the background, particularly if it involves a smooth gradient that is darker than the foreground.

The string for the background was based on Prussian Blue. The lighter values were desaturated with Cadmium Yellow and Red and then lightened with white. The darker values used Burnt Sienna instead of Cadmium Red.

Before working on the background, I adjusted the pear shapes to be a little less generic. Adjustments were in Yellow Ochre and Prussian Blue. Note in particular the restating of the lower left edge of the left pear to show a larger triangle of light blue background. The upper right edge of the left pear was restated to make the shape less generic.

The new magnetic easel really comes in handy for exacting edge work because I can easily rotate the piece I am working on. I will still have to practice painting in all directions if I want to do large paintings.

I mixed a string of four values for the background gradient, and then painted steps of these values and the three in between. I’ve found that it is best to work from the darks into the lights. When working from light to dark, the lighter values can easily obliterate the darker values because the lighter pigments tend to be opaque while the darker pigments are transparent.

I try to use a large brush wherever possible, but I’m using a small brush here because the silhouette shapes are really important.

The background gradient has been smoothed and I’ve softened the edges of the shadow shapes.

Here’s the other painting.

I didn’t go home until 2am.

Exciting Pear Pictures

Today I stumbled upon an exciting new image idea: front-lit Bosc pears casting shadows on a sky blue background. Like many ideas in art, this one was born of serendipity. I had been painting citrus with front lighting against a light blue background when my classmate Christina remarked that the shadow of my easel on the painted background created a deep dark blue that looked really nice.

Then today I was testing out a new, super bright light bulb (Philips 120W Equivalent Daylight 5000K PAR38 Dimmable LED Flood Light Bulb) with some pears and the light was bright enough to cast visible shadows in the ambient light of the studio. The interplay between the shapes of the shadows in the background and the pears in the foreground reminded me of my Less Is More print series. It seemed that any arrangement of fruit and shadows showed promise. Here is one example:

I am fascinated by the interplay of the deep blue shadow shapes and the yellow pears. This idea has lots of potential.

Since I’ve been focusing on smaller paintings recently, I decided to break the scene into two separate images, with the goal of returning to do a more complex arrangement after a bit of practice.

I love the shape of this Bosc pear. Hopefully I can paint it before it spoils.

Here’s the block in. I especially like how the front of the tabletop is bright, the top of the table is mid-tone, and the shadow of the tabletop is dark.

This is an interesting composition. I also like the reflection of the blue background on the left side of the left pear.

Here’s the second block in. I’m still not happy with the shape of the left pear, which is too generic, so I will probably adjust it as I put in the background.

My studio at the end of the evening, with both paintings resting on my new magnetic easel.

Magnetic Canvas Board Holder

At the beginning of the semester, Gage issued me a new Blick Studio Medium-Duty H-Frame Easel. I liked the easel initially, but over time I found it wasn’t suited for small studies because the top canvas holder couldn’t be positioned low enough to hold a small canvas below standing eye level.

Back in September, I had considered making a magnetic backing board that would allow greater flexibility when positioning smaller canvases, but I didn’t take action until recently when I wanted to increase my output by working on a number of smaller pieces at once.

Over the weekend, I borrowed a page from from Ulan Moore’s playbook and built a steel-faced backing board and three pairs of magnetic canvas holders. Here’s the story:

Drilling holes for magnets in 1″ x 2″ maple stock.

Each magnet will be glued into a hole. A groove along the narrow side will hold the canvas panel in place.

The magnets are held in place with epoxy. After inserting the magnets, I used the popsicle stick to spread the epoxy across the surface and then covered the magnets with piece of cardstock. The cardstock helps to hold the magnets in place and allows the piece to slide smoothly on the easel.

I taped a 24″ x 36″ piece of galvanized steel to a piece of Masonite and placed the whole assembly on my easel. The Masonite is important because the steel is too flexible by itself.

Closeup showing how the grooves in the holder grab on to the canvas panel. One of the nice things about this design is that the canvas panel is held about 1/8″ off the steel, allowing me to easily paint the edges of the panel.

I just love this setup – it works much better than I could have anticipated. It is easy to place and move the canvas panel and I can easily adjust the setup to get at all four edges.

February 11, 2014

Tonight I finished my second citrus painting. I’m finding that doing a bunch of small, quick paintings is more satisfying than a single long painting. My plan moving forward is to do a few more citrus paintings to get the hang of it and then proceed through small paintings of vegetables, paper bags, jars, etc. until I have a pretty solid repertory that I can use in more ambitious paintings.

February 10, 2014

Worked on my second citrus painting this evening. I seem to be getting the hang of painting front light on citrus. This painting went much faster than the previous one and I was actually able to get some texture onto the skin of the lemon. I’m hoping to finish up in one more session – all that remains is the table top and the reflection of the lemon.

Then I have a really nice Bosc pear and some more citrus beckoning . . .
